Python Figure Reference: scatter Traces

A plotly.graph_objects.Scatter trace is a graph object in the figure's data list with any of the named arguments or attributes listed below.

The scatter trace type encompasses line charts, scatter charts, text charts, and bubble charts. The data visualized as scatter point or lines is set in `x` and `y`. Text (appearing either on the chart or on hover only) is via `text`. Bubble charts are achieved by setting `marker.size` and/or `marker.color` to numerical arrays.

  • name
    Code: fig.update_traces(name=<VALUE>, selector=dict(type='scatter'))
    Type: string

    Sets the trace name. The trace name appears as the legend item and on hover.

  • visible
    Code: fig.update_traces(visible=<VALUE>, selector=dict(type='scatter'))
    Type: enumerated , one of ( True | False | "legendonly" )
    Default: True

    Determines whether or not this trace is visible. If "legendonly", the trace is not drawn, but can appear as a legend item (provided that the legend itself is visible).

  • showlegend
    Code: fig.update_traces(showlegend=<VALUE>, selector=dict(type='scatter'))
    Type: boolean
    Default: True

    Determines whether or not an item corresponding to this trace is shown in the legend.

  • legend
    Code: fig.update_traces(legend=<VALUE>, selector=dict(type='scatter'))
    Type: subplotid
    Default: legend

    Sets the reference to a legend to show this trace in. References to these legends are "legend", "legend2", "legend3", etc. Settings for these legends are set in the layout, under `layout.legend`, `layout.legend2`, etc.

  • legendrank
    Code: fig.update_traces(legendrank=<VALUE>, selector=dict(type='scatter'))
    Type: number
    Default: 1000

    Sets the legend rank for this trace. Items and groups with smaller ranks are presented on top/left side while with "reversed" `legend.traceorder` they are on bottom/right side. The default legendrank is 1000, so that you can use ranks less than 1000 to place certain items before all unranked items, and ranks greater than 1000 to go after all unranked items. When having unranked or equal rank items shapes would be displayed after traces i.e. according to their order in data and layout.

  • legendgroup
    Code: fig.update_traces(legendgroup=<VALUE>, selector=dict(type='scatter'))
    Type: string
    Default: ""

    Sets the legend group for this trace. Traces and shapes part of the same legend group hide/show at the same time when toggling legend items.

  • legendgrouptitle
    Code: fig.update_traces(legendgrouptitle=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.
    • font
      Code: fig.update_traces(legendgrouptitle_font=dict(...), selector=dict(type='scatter'))
      Type: dict containing one or more of the keys listed below.

      Sets this legend group's title font.

      • color
        Code: fig.update_traces(legendgrouptitle_font_color=<VALUE>, selector=dict(type='scatter'))
        Type: color
      • family
        Code: fig.update_traces(legendgrouptitle_font_family=<VALUE>, selector=dict(type='scatter'))
        Type: string

        HTML font family - the typeface that will be applied by the web browser. The web browser will only be able to apply a font if it is available on the system which it operates. Provide multiple font families, separated by commas, to indicate the preference in which to apply fonts if they aren't available on the system. The Chart Studio Cloud (at https://chart-studio.plotly.com or on-premise) generates images on a server, where only a select number of fonts are installed and supported. These include "Arial", "Balto", "Courier New", "Droid Sans", "Droid Serif", "Droid Sans Mono", "Gravitas One", "Old Standard TT", "Open Sans", "Overpass", "PT Sans Narrow", "Raleway", "Times New Roman".

      • lineposition
        Code: fig.update_traces(legendgrouptitle_font_lineposition=<VALUE>, selector=dict(type='scatter'))
        Type: flaglist string. Any combination of "under", "over", "through" joined with a "+" OR "none".
        Examples: "under", "over", "under+over", "under+over+through", "none"
        Default: "none"

        Sets the kind of decoration line(s) with text, such as an "under", "over" or "through" as well as combinations e.g. "under+over", etc.

      • shadow
        Code: fig.update_traces(legendgrouptitle_font_shadow=<VALUE>, selector=dict(type='scatter'))
        Type: string
        Default: "none"

        Sets the shape and color of the shadow behind text. "auto" places minimal shadow and applies contrast text font color. See https://developer.mozilla.org/en-US/docs/Web/CSS/text-shadow for additional options.

      • size
        Code: fig.update_traces(legendgrouptitle_font_size=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 1
      • style
        Code: fig.update_traces(legendgrouptitle_font_style=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "normal" | "italic" )
        Default: "normal"

        Sets whether a font should be styled with a normal or italic face from its family.

      • textcase
        Code: fig.update_traces(legendgrouptitle_font_textcase=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "normal" | "word caps" | "upper" | "lower" )
        Default: "normal"

        Sets capitalization of text. It can be used to make text appear in all-uppercase or all-lowercase, or with each word capitalized.

      • variant
        Code: fig.update_traces(legendgrouptitle_font_variant=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "normal" | "small-caps" | "all-small-caps" | "all-petite-caps" | "petite-caps" | "unicase" )
        Default: "normal"

        Sets the variant of the font.

      • weight
        Code: fig.update_traces(legendgrouptitle_font_weight=<VALUE>, selector=dict(type='scatter'))
        Type: integer between or equal to 1 and 1000
        Default: normal

        Sets the weight (or boldness) of the font.

    • text
      Code: fig.update_traces(legendgrouptitle_text=<VALUE>, selector=dict(type='scatter'))
      Type: string
      Default: ""

      Sets the title of the legend group.

  • legendwidth
    Code: fig.update_traces(legendwidth=<VALUE>, selector=dict(type='scatter'))
    Type: number greater than or equal to 0

    Sets the width (in px or fraction) of the legend for this trace.

  • opacity
    Code: fig.update_traces(opacity=<VALUE>, selector=dict(type='scatter'))
    Type: number between or equal to 0 and 1
    Default: 1

    Sets the opacity of the trace.

  • mode
    Code: fig.update_traces(mode=<VALUE>, selector=dict(type='scatter'))
    Type: flaglist string. Any combination of "lines", "markers", "text" joined with a "+" OR "none".
    Examples: "lines", "markers", "lines+markers", "lines+markers+text", "none"

    Determines the drawing mode for this scatter trace. If the provided `mode` includes "text" then the `text` elements appear at the coordinates. Otherwise, the `text` elements appear on hover. If there are less than 20 points and the trace is not stacked then the default is "lines+markers". Otherwise, "lines".

  • ids
    Code: fig.update_traces(ids=<VALUE>, selector=dict(type='scatter'))
    Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

    Assigns id labels to each datum. These ids for object constancy of data points during animation. Should be an array of strings, not numbers or any other type.

  • zorder
    Code: fig.update_traces(zorder=<VALUE>, selector=dict(type='scatter'))
    Type: integer
    Default: 0

    Sets the layer on which this trace is displayed, relative to other SVG traces on the same subplot. SVG traces with higher `zorder` appear in front of those with lower `zorder`.

  • x
    Code: fig.update_traces(x=<VALUE>, selector=dict(type='scatter'))
    Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

    Sets the x coordinates.

  • x0
    Code: fig.update_traces(x0=<VALUE>, selector=dict(type='scatter'))
    Type: number or categorical coordinate string
    Default: 0

    Alternate to `x`. Builds a linear space of x coordinates. Use with `dx` where `x0` is the starting coordinate and `dx` the step.

  • dx
    Code: fig.update_traces(dx=<VALUE>, selector=dict(type='scatter'))
    Type: number
    Default: 1

    Sets the x coordinate step. See `x0` for more info.

  • y
    Code: fig.update_traces(y=<VALUE>, selector=dict(type='scatter'))
    Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

    Sets the y coordinates.

  • y0
    Code: fig.update_traces(y0=<VALUE>, selector=dict(type='scatter'))
    Type: number or categorical coordinate string
    Default: 0

    Alternate to `y`. Builds a linear space of y coordinates. Use with `dy` where `y0` is the starting coordinate and `dy` the step.

  • dy
    Code: fig.update_traces(dy=<VALUE>, selector=dict(type='scatter'))
    Type: number
    Default: 1

    Sets the y coordinate step. See `y0` for more info.

  • text
    Code: fig.update_traces(text=<VALUE>, selector=dict(type='scatter'))
    Type: string or array of strings
    Default: ""

    Sets text elements associated with each (x,y) pair. If a single string, the same string appears over all the data points. If an array of string, the items are mapped in order to the this trace's (x,y) coordinates. If trace `hoverinfo` contains a "text" flag and "hovertext" is not set, these elements will be seen in the hover labels.

  • textposition
    Code: fig.update_traces(textposition=<VALUE>, selector=dict(type='scatter'))
    Type: enumerated or array of enumerateds , one of ( "top left" | "top center" | "top right" | "middle left" | "middle center" | "middle right" | "bottom left" | "bottom center" | "bottom right" )
    Default: "middle center"

    Sets the positions of the `text` elements with respects to the (x,y) coordinates.

  • texttemplate
    Code: fig.update_traces(texttemplate=<VALUE>, selector=dict(type='scatter'))
    Type: string or array of strings
    Default: ""

    Template string used for rendering the information text that appear on points. Note that this will override `textinfo`. Variables are inserted using %{variable}, for example "y: %{y}". Numbers are formatted using d3-format's syntax %{variable:d3-format}, for example "Price: %{y:$.2f}". https://github.com/d3/d3-format/tree/v1.4.5#d3-format for details on the formatting syntax. Dates are formatted using d3-time-format's syntax %{variable|d3-time-format}, for example "Day: %{2019-01-01|%A}". https://github.com/d3/d3-time-format/tree/v2.2.3#locale_format for details on the date formatting syntax. Every attributes that can be specified per-point (the ones that are `arrayOk: True`) are available.

  • hovertext
    Code: fig.update_traces(hovertext=<VALUE>, selector=dict(type='scatter'))
    Type: string or array of strings
    Default: ""

    Sets hover text elements associated with each (x,y) pair. If a single string, the same string appears over all the data points. If an array of string, the items are mapped in order to the this trace's (x,y) coordinates. To be seen, trace `hoverinfo` must contain a "text" flag.

  • hoverinfo
    Code: fig.update_traces(hoverinfo=<VALUE>, selector=dict(type='scatter'))
    Type: flaglist string. Any combination of "x", "y", "z", "text", "name" joined with a "+" OR "all" or "none" or "skip".
    Examples: "x", "y", "x+y", "x+y+z", "all"
    Default: "all"

    Determines which trace information appear on hover. If `none` or `skip` are set, no information is displayed upon hovering. But, if `none` is set, click and hover events are still fired.

  • hovertemplate
    Code: fig.update_traces(hovertemplate=<VALUE>, selector=dict(type='scatter'))
    Type: string or array of strings
    Default: ""

    Template string used for rendering the information that appear on hover box. Note that this will override `hoverinfo`. Variables are inserted using %{variable}, for example "y: %{y}" as well as %{xother}, {%_xother}, {%_xother_}, {%xother_}. When showing info for several points, "xother" will be added to those with different x positions from the first point. An underscore before or after "(x|y)other" will add a space on that side, only when this field is shown. Numbers are formatted using d3-format's syntax %{variable:d3-format}, for example "Price: %{y:$.2f}". https://github.com/d3/d3-format/tree/v1.4.5#d3-format for details on the formatting syntax. Dates are formatted using d3-time-format's syntax %{variable|d3-time-format}, for example "Day: %{2019-01-01|%A}". https://github.com/d3/d3-time-format/tree/v2.2.3#locale_format for details on the date formatting syntax. The variables available in `hovertemplate` are the ones emitted as event data described at this link https://plotly.com/javascript/plotlyjs-events/#event-data. Additionally, every attributes that can be specified per-point (the ones that are `arrayOk: True`) are available. Anything contained in tag `<extra>` is displayed in the secondary box, for example "<extra>{fullData.name}</extra>". To hide the secondary box completely, use an empty tag `<extra></extra>`.

  • xhoverformat
    Code: fig.update_traces(xhoverformat=<VALUE>, selector=dict(type='scatter'))
    Type: string
    Default: ""

    Sets the hover text formatting rulefor `x` using d3 formatting mini-languages which are very similar to those in Python. For numbers, see: https://github.com/d3/d3-format/tree/v1.4.5#d3-format. And for dates see: https://github.com/d3/d3-time-format/tree/v2.2.3#locale_format. We add two items to d3's date formatter: "%h" for half of the year as a decimal number as well as "%{n}f" for fractional seconds with n digits. For example, "2016-10-13 09:15:23.456" with tickformat "%H~%M~%S.%2f" would display "09~15~23.46"By default the values are formatted using `xaxis.hoverformat`.

  • yhoverformat
    Code: fig.update_traces(yhoverformat=<VALUE>, selector=dict(type='scatter'))
    Type: string
    Default: ""

    Sets the hover text formatting rulefor `y` using d3 formatting mini-languages which are very similar to those in Python. For numbers, see: https://github.com/d3/d3-format/tree/v1.4.5#d3-format. And for dates see: https://github.com/d3/d3-time-format/tree/v2.2.3#locale_format. We add two items to d3's date formatter: "%h" for half of the year as a decimal number as well as "%{n}f" for fractional seconds with n digits. For example, "2016-10-13 09:15:23.456" with tickformat "%H~%M~%S.%2f" would display "09~15~23.46"By default the values are formatted using `yaxis.hoverformat`.

  • meta
    Code: fig.update_traces(meta=<VALUE>, selector=dict(type='scatter'))
    Type: number or categorical coordinate string

    Assigns extra meta information associated with this trace that can be used in various text attributes. Attributes such as trace `name`, graph, axis and colorbar `title.text`, annotation `text` `rangeselector`, `updatemenues` and `sliders` `label` text all support `meta`. To access the trace `meta` values in an attribute in the same trace, simply use `%{meta[i]}` where `i` is the index or key of the `meta` item in question. To access trace `meta` in layout attributes, use `%{data[n[.meta[i]}` where `i` is the index or key of the `meta` and `n` is the trace index.

  • customdata
    Code: fig.update_traces(customdata=<VALUE>, selector=dict(type='scatter'))
    Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

    Assigns extra data each datum. This may be useful when listening to hover, click and selection events. Note that, "scatter" traces also appends customdata items in the markers DOM elements

  • xaxis
    Code: fig.update_traces(xaxis=<VALUE>, selector=dict(type='scatter'))
    Type: subplotid
    Default: x

    Sets a reference between this trace's x coordinates and a 2D cartesian x axis. If "x" (the default value), the x coordinates refer to `layout.xaxis`. If "x2", the x coordinates refer to `layout.xaxis2`, and so on.

  • yaxis
    Code: fig.update_traces(yaxis=<VALUE>, selector=dict(type='scatter'))
    Type: subplotid
    Default: y

    Sets a reference between this trace's y coordinates and a 2D cartesian y axis. If "y" (the default value), the y coordinates refer to `layout.yaxis`. If "y2", the y coordinates refer to `layout.yaxis2`, and so on.

  • orientation
    Code: fig.update_traces(orientation=<VALUE>, selector=dict(type='scatter'))
    Type: enumerated , one of ( "v" | "h" )

    Only relevant in the following cases: 1. when `scattermode` is set to "group". 2. when `stackgroup` is used, and only the first `orientation` found in the `stackgroup` will be used - including if `visible` is "legendonly" but not if it is `False`. Sets the stacking direction. With "v" ("h"), the y (x) values of subsequent traces are added. Also affects the default value of `fill`.

  • groupnorm
    Code: fig.update_traces(groupnorm=<VALUE>, selector=dict(type='scatter'))
    Type: enumerated , one of ( "" | "fraction" | "percent" )
    Default: ""

    Only relevant when `stackgroup` is used, and only the first `groupnorm` found in the `stackgroup` will be used - including if `visible` is "legendonly" but not if it is `False`. Sets the normalization for the sum of this `stackgroup`. With "fraction", the value of each trace at each location is divided by the sum of all trace values at that location. "percent" is the same but multiplied by 100 to show percentages. If there are multiple subplots, or multiple `stackgroup`s on one subplot, each will be normalized within its own set.

  • alignmentgroup
    Code: fig.update_traces(alignmentgroup=<VALUE>, selector=dict(type='scatter'))
    Type: string
    Default: ""

    Set several traces linked to the same position axis or matching axes to the same alignmentgroup. This controls whether bars compute their positional range dependently or independently.

  • offsetgroup
    Code: fig.update_traces(offsetgroup=<VALUE>, selector=dict(type='scatter'))
    Type: string
    Default: ""

    Set several traces linked to the same position axis or matching axes to the same offsetgroup where bars of the same position coordinate will line up.

  • stackgroup
    Code: fig.update_traces(stackgroup=<VALUE>, selector=dict(type='scatter'))
    Type: string
    Default: ""

    Set several scatter traces (on the same subplot) to the same stackgroup in order to add their y values (or their x values if `orientation` is "h"). If blank or omitted this trace will not be stacked. Stacking also turns `fill` on by default, using "tonexty" ("tonextx") if `orientation` is "h" ("v") and sets the default `mode` to "lines" irrespective of point count. You can only stack on a numeric (linear or log) axis. Traces in a `stackgroup` will only fill to (or be filled to) other traces in the same group. With multiple `stackgroup`s or some traces stacked and some not, if fill-linked traces are not already consecutive, the later ones will be pushed down in the drawing order.

  • xperiod
    Code: fig.update_traces(xperiod=<VALUE>, selector=dict(type='scatter'))
    Type: number or categorical coordinate string
    Default: 0

    Only relevant when the axis `type` is "date". Sets the period positioning in milliseconds or "M<n>" on the x axis. Special values in the form of "M<n>" could be used to declare the number of months. In this case `n` must be a positive integer.

  • xperiodalignment
    Code: fig.update_traces(xperiodalignment=<VALUE>, selector=dict(type='scatter'))
    Type: enumerated , one of ( "start" | "middle" | "end" )
    Default: "middle"

    Only relevant when the axis `type` is "date". Sets the alignment of data points on the x axis.

  • xperiod0
    Code: fig.update_traces(xperiod0=<VALUE>, selector=dict(type='scatter'))
    Type: number or categorical coordinate string

    Only relevant when the axis `type` is "date". Sets the base for period positioning in milliseconds or date string on the x0 axis. When `x0period` is round number of weeks, the `x0period0` by default would be on a Sunday i.e. 2000-01-02, otherwise it would be at 2000-01-01.

  • yperiod
    Code: fig.update_traces(yperiod=<VALUE>, selector=dict(type='scatter'))
    Type: number or categorical coordinate string
    Default: 0

    Only relevant when the axis `type` is "date". Sets the period positioning in milliseconds or "M<n>" on the y axis. Special values in the form of "M<n>" could be used to declare the number of months. In this case `n` must be a positive integer.

  • yperiodalignment
    Code: fig.update_traces(yperiodalignment=<VALUE>, selector=dict(type='scatter'))
    Type: enumerated , one of ( "start" | "middle" | "end" )
    Default: "middle"

    Only relevant when the axis `type` is "date". Sets the alignment of data points on the y axis.

  • yperiod0
    Code: fig.update_traces(yperiod0=<VALUE>, selector=dict(type='scatter'))
    Type: number or categorical coordinate string

    Only relevant when the axis `type` is "date". Sets the base for period positioning in milliseconds or date string on the y0 axis. When `y0period` is round number of weeks, the `y0period0` by default would be on a Sunday i.e. 2000-01-02, otherwise it would be at 2000-01-01.

  • marker
    Code: fig.update_traces(marker=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.
    • angle
      Code: fig.update_traces(marker_angle=<VALUE>, selector=dict(type='scatter'))
      Type: angle
      Default: 0

      Sets the marker angle in respect to `angleref`.

    • angleref
      Code: fig.update_traces(marker_angleref=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated , one of ( "previous" | "up" )
      Default: "up"

      Sets the reference for marker angle. With "previous", angle 0 points along the line from the previous point to this one. With "up", angle 0 points toward the top of the screen.

    • autocolorscale
      Code: fig.update_traces(marker_autocolorscale=<VALUE>, selector=dict(type='scatter'))
      Type: boolean
      Default: True

      Determines whether the colorscale is a default palette (`autocolorscale: True`) or the palette determined by `marker.colorscale`. Has an effect only if in `marker.color` is set to a numerical array. In case `colorscale` is unspecified or `autocolorscale` is True, the default palette will be chosen according to whether numbers in the `color` array are all positive, all negative or mixed.

    • cauto
      Code: fig.update_traces(marker_cauto=<VALUE>, selector=dict(type='scatter'))
      Type: boolean
      Default: True

      Determines whether or not the color domain is computed with respect to the input data (here in `marker.color`) or the bounds set in `marker.cmin` and `marker.cmax` Has an effect only if in `marker.color` is set to a numerical array. Defaults to `False` when `marker.cmin` and `marker.cmax` are set by the user.

    • cmax
      Code: fig.update_traces(marker_cmax=<VALUE>, selector=dict(type='scatter'))
      Type: number

      Sets the upper bound of the color domain. Has an effect only if in `marker.color` is set to a numerical array. Value should have the same units as in `marker.color` and if set, `marker.cmin` must be set as well.

    • cmid
      Code: fig.update_traces(marker_cmid=<VALUE>, selector=dict(type='scatter'))
      Type: number

      Sets the mid-point of the color domain by scaling `marker.cmin` and/or `marker.cmax` to be equidistant to this point. Has an effect only if in `marker.color` is set to a numerical array. Value should have the same units as in `marker.color`. Has no effect when `marker.cauto` is `False`.

    • cmin
      Code: fig.update_traces(marker_cmin=<VALUE>, selector=dict(type='scatter'))
      Type: number

      Sets the lower bound of the color domain. Has an effect only if in `marker.color` is set to a numerical array. Value should have the same units as in `marker.color` and if set, `marker.cmax` must be set as well.

    • color
      Code: fig.update_traces(marker_color=<VALUE>, selector=dict(type='scatter'))
      Type: color or array of colors

      Sets the marker color. It accepts either a specific color or an array of numbers that are mapped to the colorscale relative to the max and min values of the array or relative to `marker.cmin` and `marker.cmax` if set.

    • coloraxis
      Code: fig.update_traces(marker_coloraxis=<VALUE>, selector=dict(type='scatter'))
      Type: subplotid

      Sets a reference to a shared color axis. References to these shared color axes are "coloraxis", "coloraxis2", "coloraxis3", etc. Settings for these shared color axes are set in the layout, under `layout.coloraxis`, `layout.coloraxis2`, etc. Note that multiple color scales can be linked to the same color axis.

    • colorbar
      Code: fig.update_traces(marker_colorbar=dict(...), selector=dict(type='scatter'))
      Type: dict containing one or more of the keys listed below.
      • bgcolor
        Code: fig.update_traces(marker_colorbar_bgcolor=<VALUE>, selector=dict(type='scatter'))
        Type: color
        Default: "rgba(0,0,0,0)"

        Sets the color of padded area.

      • bordercolor
        Code: fig.update_traces(marker_colorbar_bordercolor=<VALUE>, selector=dict(type='scatter'))
        Type: color
        Default: "#444"

        Sets the axis line color.

      • borderwidth
        Code: fig.update_traces(marker_colorbar_borderwidth=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0
        Default: 0

        Sets the width (in px) or the border enclosing this color bar.

      • dtick
        Code: fig.update_traces(marker_colorbar_dtick=<VALUE>, selector=dict(type='scatter'))
        Type: number or categorical coordinate string

        Sets the step in-between ticks on this axis. Use with `tick0`. Must be a positive number, or special strings available to "log" and "date" axes. If the axis `type` is "log", then ticks are set every 10^(n"dtick) where n is the tick number. For example, to set a tick mark at 1, 10, 100, 1000, ... set dtick to 1. To set tick marks at 1, 100, 10000, ... set dtick to 2. To set tick marks at 1, 5, 25, 125, 625, 3125, ... set dtick to log_10(5), or 0.69897000433. "log" has several special values; "L<f>", where `f` is a positive number, gives ticks linearly spaced in value (but not position). For example `tick0` = 0.1, `dtick` = "L0.5" will put ticks at 0.1, 0.6, 1.1, 1.6 etc. To show powers of 10 plus small digits between, use "D1" (all digits) or "D2" (only 2 and 5). `tick0` is ignored for "D1" and "D2". If the axis `type` is "date", then you must convert the time to milliseconds. For example, to set the interval between ticks to one day, set `dtick` to 86400000.0. "date" also has special values "M<n>" gives ticks spaced by a number of months. `n` must be a positive integer. To set ticks on the 15th of every third month, set `tick0` to "2000-01-15" and `dtick` to "M3". To set ticks every 4 years, set `dtick` to "M48"

      • exponentformat
        Code: fig.update_traces(marker_colorbar_exponentformat=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "none" | "e" | "E" | "power" | "SI" | "B" )
        Default: "B"

        Determines a formatting rule for the tick exponents. For example, consider the number 1,000,000,000. If "none", it appears as 1,000,000,000. If "e", 1e+9. If "E", 1E+9. If "power", 1x10^9 (with 9 in a super script). If "SI", 1G. If "B", 1B.

      • labelalias
        Code: fig.update_traces(marker_colorbar_labelalias=<VALUE>, selector=dict(type='scatter'))
        Type: number or categorical coordinate string

        Replacement text for specific tick or hover labels. For example using {US: 'USA', CA: 'Canada'} changes US to USA and CA to Canada. The labels we would have shown must match the keys exactly, after adding any tickprefix or ticksuffix. For negative numbers the minus sign symbol used (U+2212) is wider than the regular ascii dash. That means you need to use −1 instead of -1. labelalias can be used with any axis type, and both keys (if needed) and values (if desired) can include html-like tags or MathJax.

      • len
        Code: fig.update_traces(marker_colorbar_len=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0
        Default: 1

        Sets the length of the color bar This measure excludes the padding of both ends. That is, the color bar length is this length minus the padding on both ends.

      • lenmode
        Code: fig.update_traces(marker_colorbar_lenmode=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "fraction" | "pixels" )
        Default: "fraction"

        Determines whether this color bar's length (i.e. the measure in the color variation direction) is set in units of plot "fraction" or in "pixels. Use `len` to set the value.

      • minexponent
        Code: fig.update_traces(marker_colorbar_minexponent=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0
        Default: 3

        Hide SI prefix for 10^n if |n| is below this number. This only has an effect when `tickformat` is "SI" or "B".

      • nticks
        Code: fig.update_traces(marker_colorbar_nticks=<VALUE>, selector=dict(type='scatter'))
        Type: integer greater than or equal to 0
        Default: 0

        Specifies the maximum number of ticks for the particular axis. The actual number of ticks will be chosen automatically to be less than or equal to `nticks`. Has an effect only if `tickmode` is set to "auto".

      • orientation
        Code: fig.update_traces(marker_colorbar_orientation=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "h" | "v" )
        Default: "v"

        Sets the orientation of the colorbar.

      • outlinecolor
        Code: fig.update_traces(marker_colorbar_outlinecolor=<VALUE>, selector=dict(type='scatter'))
        Type: color
        Default: "#444"

        Sets the axis line color.

      • outlinewidth
        Code: fig.update_traces(marker_colorbar_outlinewidth=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0
        Default: 1

        Sets the width (in px) of the axis line.

      • separatethousands
        Code: fig.update_traces(marker_colorbar_separatethousands=<VALUE>, selector=dict(type='scatter'))
        Type: boolean

        If "True", even 4-digit integers are separated

      • showexponent
        Code: fig.update_traces(marker_colorbar_showexponent=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "all" | "first" | "last" | "none" )
        Default: "all"

        If "all", all exponents are shown besides their significands. If "first", only the exponent of the first tick is shown. If "last", only the exponent of the last tick is shown. If "none", no exponents appear.

      • showticklabels
        Code: fig.update_traces(marker_colorbar_showticklabels=<VALUE>, selector=dict(type='scatter'))
        Type: boolean
        Default: True

        Determines whether or not the tick labels are drawn.

      • showtickprefix
        Code: fig.update_traces(marker_colorbar_showtickprefix=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "all" | "first" | "last" | "none" )
        Default: "all"

        If "all", all tick labels are displayed with a prefix. If "first", only the first tick is displayed with a prefix. If "last", only the last tick is displayed with a suffix. If "none", tick prefixes are hidden.

      • showticksuffix
        Code: fig.update_traces(marker_colorbar_showticksuffix=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "all" | "first" | "last" | "none" )
        Default: "all"

        Same as `showtickprefix` but for tick suffixes.

      • thickness
        Code: fig.update_traces(marker_colorbar_thickness=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0
        Default: 30

        Sets the thickness of the color bar This measure excludes the size of the padding, ticks and labels.

      • thicknessmode
        Code: fig.update_traces(marker_colorbar_thicknessmode=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "fraction" | "pixels" )
        Default: "pixels"

        Determines whether this color bar's thickness (i.e. the measure in the constant color direction) is set in units of plot "fraction" or in "pixels". Use `thickness` to set the value.

      • tick0
        Code: fig.update_traces(marker_colorbar_tick0=<VALUE>, selector=dict(type='scatter'))
        Type: number or categorical coordinate string

        Sets the placement of the first tick on this axis. Use with `dtick`. If the axis `type` is "log", then you must take the log of your starting tick (e.g. to set the starting tick to 100, set the `tick0` to 2) except when `dtick`="L<f>" (see `dtick` for more info). If the axis `type` is "date", it should be a date string, like date data. If the axis `type` is "category", it should be a number, using the scale where each category is assigned a serial number from zero in the order it appears.

      • tickangle
        Code: fig.update_traces(marker_colorbar_tickangle=<VALUE>, selector=dict(type='scatter'))
        Type: angle
        Default: "auto"

        Sets the angle of the tick labels with respect to the horizontal. For example, a `tickangle` of -90 draws the tick labels vertically.

      • tickcolor
        Code: fig.update_traces(marker_colorbar_tickcolor=<VALUE>, selector=dict(type='scatter'))
        Type: color
        Default: "#444"

        Sets the tick color.

      • tickfont
        Code: fig.update_traces(marker_colorbar_tickfont=dict(...), selector=dict(type='scatter'))
        Type: dict containing one or more of the keys listed below.

        Sets the color bar's tick label font

        • color
          Code: fig.update_traces(marker_colorbar_tickfont_color=<VALUE>, selector=dict(type='scatter'))
          Type: color
        • family
          Code: fig.update_traces(marker_colorbar_tickfont_family=<VALUE>, selector=dict(type='scatter'))
          Type: string

          HTML font family - the typeface that will be applied by the web browser. The web browser will only be able to apply a font if it is available on the system which it operates. Provide multiple font families, separated by commas, to indicate the preference in which to apply fonts if they aren't available on the system. The Chart Studio Cloud (at https://chart-studio.plotly.com or on-premise) generates images on a server, where only a select number of fonts are installed and supported. These include "Arial", "Balto", "Courier New", "Droid Sans", "Droid Serif", "Droid Sans Mono", "Gravitas One", "Old Standard TT", "Open Sans", "Overpass", "PT Sans Narrow", "Raleway", "Times New Roman".

        • lineposition
          Code: fig.update_traces(marker_colorbar_tickfont_lineposition=<VALUE>, selector=dict(type='scatter'))
          Type: flaglist string. Any combination of "under", "over", "through" joined with a "+" OR "none".
          Examples: "under", "over", "under+over", "under+over+through", "none"
          Default: "none"

          Sets the kind of decoration line(s) with text, such as an "under", "over" or "through" as well as combinations e.g. "under+over", etc.

        • shadow
          Code: fig.update_traces(marker_colorbar_tickfont_shadow=<VALUE>, selector=dict(type='scatter'))
          Type: string
          Default: "none"

          Sets the shape and color of the shadow behind text. "auto" places minimal shadow and applies contrast text font color. See https://developer.mozilla.org/en-US/docs/Web/CSS/text-shadow for additional options.

        • size
          Code: fig.update_traces(marker_colorbar_tickfont_size=<VALUE>, selector=dict(type='scatter'))
          Type: number greater than or equal to 1
        • style
          Code: fig.update_traces(marker_colorbar_tickfont_style=<VALUE>, selector=dict(type='scatter'))
          Type: enumerated , one of ( "normal" | "italic" )
          Default: "normal"

          Sets whether a font should be styled with a normal or italic face from its family.

        • textcase
          Code: fig.update_traces(marker_colorbar_tickfont_textcase=<VALUE>, selector=dict(type='scatter'))
          Type: enumerated , one of ( "normal" | "word caps" | "upper" | "lower" )
          Default: "normal"

          Sets capitalization of text. It can be used to make text appear in all-uppercase or all-lowercase, or with each word capitalized.

        • variant
          Code: fig.update_traces(marker_colorbar_tickfont_variant=<VALUE>, selector=dict(type='scatter'))
          Type: enumerated , one of ( "normal" | "small-caps" | "all-small-caps" | "all-petite-caps" | "petite-caps" | "unicase" )
          Default: "normal"

          Sets the variant of the font.

        • weight
          Code: fig.update_traces(marker_colorbar_tickfont_weight=<VALUE>, selector=dict(type='scatter'))
          Type: integer between or equal to 1 and 1000
          Default: normal

          Sets the weight (or boldness) of the font.

      • tickformat
        Code: fig.update_traces(marker_colorbar_tickformat=<VALUE>, selector=dict(type='scatter'))
        Type: string
        Default: ""

        Sets the tick label formatting rule using d3 formatting mini-languages which are very similar to those in Python. For numbers, see: https://github.com/d3/d3-format/tree/v1.4.5#d3-format. And for dates see: https://github.com/d3/d3-time-format/tree/v2.2.3#locale_format. We add two items to d3's date formatter: "%h" for half of the year as a decimal number as well as "%{n}f" for fractional seconds with n digits. For example, "2016-10-13 09:15:23.456" with tickformat "%H~%M~%S.%2f" would display "09~15~23.46"

      • tickformatstops
        Code: fig.update_traces(marker_colorbar_tickformatstops=list(...), selector=dict(type='scatter'))
        Type: list of dict where each dict has one or more of the keys listed below.
        • dtickrange
          Parent: data[type=scatter].marker.colorbar.tickformatstops[]
          Type: list

          range ["min", "max"], where "min", "max" - dtick values which describe some zoom level, it is possible to omit "min" or "max" value by passing "null"

        • enabled
          Parent: data[type=scatter].marker.colorbar.tickformatstops[]
          Type: boolean
          Default: True

          Determines whether or not this stop is used. If `False`, this stop is ignored even within its `dtickrange`.

        • name
          Parent: data[type=scatter].marker.colorbar.tickformatstops[]
          Type: string

          When used in a template, named items are created in the output figure in addition to any items the figure already has in this array. You can modify these items in the output figure by making your own item with `templateitemname` matching this `name` alongside your modifications (including `visible: False` or `enabled: False` to hide it). Has no effect outside of a template.

        • templateitemname
          Parent: data[type=scatter].marker.colorbar.tickformatstops[]
          Type: string

          Used to refer to a named item in this array in the template. Named items from the template will be created even without a matching item in the input figure, but you can modify one by making an item with `templateitemname` matching its `name`, alongside your modifications (including `visible: False` or `enabled: False` to hide it). If there is no template or no matching item, this item will be hidden unless you explicitly show it with `visible: True`.

        • value
          Parent: data[type=scatter].marker.colorbar.tickformatstops[]
          Type: string
          Default: ""

          string - dtickformat for described zoom level, the same as "tickformat"

      • ticklabeloverflow
        Code: fig.update_traces(marker_colorbar_ticklabeloverflow=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "allow" | "hide past div" | "hide past domain" )

        Determines how we handle tick labels that would overflow either the graph div or the domain of the axis. The default value for inside tick labels is "hide past domain". In other cases the default is "hide past div".

      • ticklabelposition
        Code: fig.update_traces(marker_colorbar_ticklabelposition=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "outside" | "inside" | "outside top" | "inside top" | "outside left" | "inside left" | "outside right" | "inside right" | "outside bottom" | "inside bottom" )
        Default: "outside"

        Determines where tick labels are drawn relative to the ticks. Left and right options are used when `orientation` is "h", top and bottom when `orientation` is "v".

      • ticklabelstep
        Code: fig.update_traces(marker_colorbar_ticklabelstep=<VALUE>, selector=dict(type='scatter'))
        Type: integer greater than or equal to 1
        Default: 1

        Sets the spacing between tick labels as compared to the spacing between ticks. A value of 1 (default) means each tick gets a label. A value of 2 means shows every 2nd label. A larger value n means only every nth tick is labeled. `tick0` determines which labels are shown. Not implemented for axes with `type` "log" or "multicategory", or when `tickmode` is "array".

      • ticklen
        Code: fig.update_traces(marker_colorbar_ticklen=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0
        Default: 5

        Sets the tick length (in px).

      • tickmode
        Code: fig.update_traces(marker_colorbar_tickmode=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "auto" | "linear" | "array" )

        Sets the tick mode for this axis. If "auto", the number of ticks is set via `nticks`. If "linear", the placement of the ticks is determined by a starting position `tick0` and a tick step `dtick` ("linear" is the default value if `tick0` and `dtick` are provided). If "array", the placement of the ticks is set via `tickvals` and the tick text is `ticktext`. ("array" is the default value if `tickvals` is provided).

      • tickprefix
        Code: fig.update_traces(marker_colorbar_tickprefix=<VALUE>, selector=dict(type='scatter'))
        Type: string
        Default: ""

        Sets a tick label prefix.

      • ticks
        Code: fig.update_traces(marker_colorbar_ticks=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "outside" | "inside" | "" )
        Default: ""

        Determines whether ticks are drawn or not. If "", this axis' ticks are not drawn. If "outside" ("inside"), this axis' are drawn outside (inside) the axis lines.

      • ticksuffix
        Code: fig.update_traces(marker_colorbar_ticksuffix=<VALUE>, selector=dict(type='scatter'))
        Type: string
        Default: ""

        Sets a tick label suffix.

      • ticktext
        Code: fig.update_traces(marker_colorbar_ticktext=<VALUE>, selector=dict(type='scatter'))
        Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

        Sets the text displayed at the ticks position via `tickvals`. Only has an effect if `tickmode` is set to "array". Used with `tickvals`.

      • tickvals
        Code: fig.update_traces(marker_colorbar_tickvals=<VALUE>, selector=dict(type='scatter'))
        Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

        Sets the values at which ticks on this axis appear. Only has an effect if `tickmode` is set to "array". Used with `ticktext`.

      • tickwidth
        Code: fig.update_traces(marker_colorbar_tickwidth=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0
        Default: 1

        Sets the tick width (in px).

      • title
        Code: fig.update_traces(marker_colorbar_title=dict(...), selector=dict(type='scatter'))
        Type: dict containing one or more of the keys listed below.
        • font
          Code: fig.update_traces(marker_colorbar_title_font=dict(...), selector=dict(type='scatter'))
          Type: dict containing one or more of the keys listed below.

          Sets this color bar's title font. Note that the title's font used to be set by the now deprecated `titlefont` attribute.

          • color
            Code: fig.update_traces(marker_colorbar_title_font_color=<VALUE>, selector=dict(type='scatter'))
            Type: color
          • family
            Code: fig.update_traces(marker_colorbar_title_font_family=<VALUE>, selector=dict(type='scatter'))
            Type: string

            HTML font family - the typeface that will be applied by the web browser. The web browser will only be able to apply a font if it is available on the system which it operates. Provide multiple font families, separated by commas, to indicate the preference in which to apply fonts if they aren't available on the system. The Chart Studio Cloud (at https://chart-studio.plotly.com or on-premise) generates images on a server, where only a select number of fonts are installed and supported. These include "Arial", "Balto", "Courier New", "Droid Sans", "Droid Serif", "Droid Sans Mono", "Gravitas One", "Old Standard TT", "Open Sans", "Overpass", "PT Sans Narrow", "Raleway", "Times New Roman".

          • lineposition
            Code: fig.update_traces(marker_colorbar_title_font_lineposition=<VALUE>, selector=dict(type='scatter'))
            Type: flaglist string. Any combination of "under", "over", "through" joined with a "+" OR "none".
            Examples: "under", "over", "under+over", "under+over+through", "none"
            Default: "none"

            Sets the kind of decoration line(s) with text, such as an "under", "over" or "through" as well as combinations e.g. "under+over", etc.

          • shadow
            Code: fig.update_traces(marker_colorbar_title_font_shadow=<VALUE>, selector=dict(type='scatter'))
            Type: string
            Default: "none"

            Sets the shape and color of the shadow behind text. "auto" places minimal shadow and applies contrast text font color. See https://developer.mozilla.org/en-US/docs/Web/CSS/text-shadow for additional options.

          • size
            Code: fig.update_traces(marker_colorbar_title_font_size=<VALUE>, selector=dict(type='scatter'))
            Type: number greater than or equal to 1
          • style
            Code: fig.update_traces(marker_colorbar_title_font_style=<VALUE>, selector=dict(type='scatter'))
            Type: enumerated , one of ( "normal" | "italic" )
            Default: "normal"

            Sets whether a font should be styled with a normal or italic face from its family.

          • textcase
            Code: fig.update_traces(marker_colorbar_title_font_textcase=<VALUE>, selector=dict(type='scatter'))
            Type: enumerated , one of ( "normal" | "word caps" | "upper" | "lower" )
            Default: "normal"

            Sets capitalization of text. It can be used to make text appear in all-uppercase or all-lowercase, or with each word capitalized.

          • variant
            Code: fig.update_traces(marker_colorbar_title_font_variant=<VALUE>, selector=dict(type='scatter'))
            Type: enumerated , one of ( "normal" | "small-caps" | "all-small-caps" | "all-petite-caps" | "petite-caps" | "unicase" )
            Default: "normal"

            Sets the variant of the font.

          • weight
            Code: fig.update_traces(marker_colorbar_title_font_weight=<VALUE>, selector=dict(type='scatter'))
            Type: integer between or equal to 1 and 1000
            Default: normal

            Sets the weight (or boldness) of the font.

        • side
          Code: fig.update_traces(marker_colorbar_title_side=<VALUE>, selector=dict(type='scatter'))
          Type: enumerated , one of ( "right" | "top" | "bottom" )

          Determines the location of color bar's title with respect to the color bar. Defaults to "top" when `orientation` if "v" and defaults to "right" when `orientation` if "h". Note that the title's location used to be set by the now deprecated `titleside` attribute.

        • text
          Code: fig.update_traces(marker_colorbar_title_text=<VALUE>, selector=dict(type='scatter'))
          Type: string

          Sets the title of the color bar. Note that before the existence of `title.text`, the title's contents used to be defined as the `title` attribute itself. This behavior has been deprecated.

      • x
        Code: fig.update_traces(marker_colorbar_x=<VALUE>, selector=dict(type='scatter'))
        Type: number

        Sets the x position with respect to `xref` of the color bar (in plot fraction). When `xref` is "paper", defaults to 1.02 when `orientation` is "v" and 0.5 when `orientation` is "h". When `xref` is "container", defaults to "1" when `orientation` is "v" and 0.5 when `orientation` is "h". Must be between "0" and "1" if `xref` is "container" and between "-2" and "3" if `xref` is "paper".

      • xanchor
        Code: fig.update_traces(marker_colorbar_xanchor=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "left" | "center" | "right" )

        Sets this color bar's horizontal position anchor. This anchor binds the `x` position to the "left", "center" or "right" of the color bar. Defaults to "left" when `orientation` is "v" and "center" when `orientation` is "h".

      • xpad
        Code: fig.update_traces(marker_colorbar_xpad=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0
        Default: 10

        Sets the amount of padding (in px) along the x direction.

      • xref
        Code: fig.update_traces(marker_colorbar_xref=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "container" | "paper" )
        Default: "paper"

        Sets the container `x` refers to. "container" spans the entire `width` of the plot. "paper" refers to the width of the plotting area only.

      • y
        Code: fig.update_traces(marker_colorbar_y=<VALUE>, selector=dict(type='scatter'))
        Type: number

        Sets the y position with respect to `yref` of the color bar (in plot fraction). When `yref` is "paper", defaults to 0.5 when `orientation` is "v" and 1.02 when `orientation` is "h". When `yref` is "container", defaults to 0.5 when `orientation` is "v" and 1 when `orientation` is "h". Must be between "0" and "1" if `yref` is "container" and between "-2" and "3" if `yref` is "paper".

      • yanchor
        Code: fig.update_traces(marker_colorbar_yanchor=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "top" | "middle" | "bottom" )

        Sets this color bar's vertical position anchor This anchor binds the `y` position to the "top", "middle" or "bottom" of the color bar. Defaults to "middle" when `orientation` is "v" and "bottom" when `orientation` is "h".

      • ypad
        Code: fig.update_traces(marker_colorbar_ypad=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0
        Default: 10

        Sets the amount of padding (in px) along the y direction.

      • yref
        Code: fig.update_traces(marker_colorbar_yref=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated , one of ( "container" | "paper" )
        Default: "paper"

        Sets the container `y` refers to. "container" spans the entire `height` of the plot. "paper" refers to the height of the plotting area only.

    • colorscale
      Code: fig.update_traces(marker_colorscale=<VALUE>, selector=dict(type='scatter'))
      Type: colorscale

      Sets the colorscale. Has an effect only if in `marker.color` is set to a numerical array. The colorscale must be an array containing arrays mapping a normalized value to an rgb, rgba, hex, hsl, hsv, or named color string. At minimum, a mapping for the lowest (0) and highest (1) values are required. For example, `[[0, 'rgb(0,0,255)'], [1, 'rgb(255,0,0)']]`. To control the bounds of the colorscale in color space, use `marker.cmin` and `marker.cmax`. Alternatively, `colorscale` may be a palette name string of the following list: Blackbody,Bluered,Blues,Cividis,Earth,Electric,Greens,Greys,Hot,Jet,Picnic,Portland,Rainbow,RdBu,Reds,Viridis,YlGnBu,YlOrRd.

    • gradient
      Code: fig.update_traces(marker_gradient=dict(...), selector=dict(type='scatter'))
      Type: dict containing one or more of the keys listed below.
      • color
        Code: fig.update_traces(marker_gradient_color=<VALUE>, selector=dict(type='scatter'))
        Type: color or array of colors

        Sets the final color of the gradient fill: the center color for radial, the right for horizontal, or the bottom for vertical.

      • type
        Code: fig.update_traces(marker_gradient_type=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated or array of enumerateds , one of ( "radial" | "horizontal" | "vertical" | "none" )
        Default: "none"

        Sets the type of gradient used to fill the markers

    • line
      Code: fig.update_traces(marker_line=dict(...), selector=dict(type='scatter'))
      Type: dict containing one or more of the keys listed below.
      • autocolorscale
        Code: fig.update_traces(marker_line_autocolorscale=<VALUE>, selector=dict(type='scatter'))
        Type: boolean
        Default: True

        Determines whether the colorscale is a default palette (`autocolorscale: True`) or the palette determined by `marker.line.colorscale`. Has an effect only if in `marker.line.color` is set to a numerical array. In case `colorscale` is unspecified or `autocolorscale` is True, the default palette will be chosen according to whether numbers in the `color` array are all positive, all negative or mixed.

      • cauto
        Code: fig.update_traces(marker_line_cauto=<VALUE>, selector=dict(type='scatter'))
        Type: boolean
        Default: True

        Determines whether or not the color domain is computed with respect to the input data (here in `marker.line.color`) or the bounds set in `marker.line.cmin` and `marker.line.cmax` Has an effect only if in `marker.line.color` is set to a numerical array. Defaults to `False` when `marker.line.cmin` and `marker.line.cmax` are set by the user.

      • cmax
        Code: fig.update_traces(marker_line_cmax=<VALUE>, selector=dict(type='scatter'))
        Type: number

        Sets the upper bound of the color domain. Has an effect only if in `marker.line.color` is set to a numerical array. Value should have the same units as in `marker.line.color` and if set, `marker.line.cmin` must be set as well.

      • cmid
        Code: fig.update_traces(marker_line_cmid=<VALUE>, selector=dict(type='scatter'))
        Type: number

        Sets the mid-point of the color domain by scaling `marker.line.cmin` and/or `marker.line.cmax` to be equidistant to this point. Has an effect only if in `marker.line.color` is set to a numerical array. Value should have the same units as in `marker.line.color`. Has no effect when `marker.line.cauto` is `False`.

      • cmin
        Code: fig.update_traces(marker_line_cmin=<VALUE>, selector=dict(type='scatter'))
        Type: number

        Sets the lower bound of the color domain. Has an effect only if in `marker.line.color` is set to a numerical array. Value should have the same units as in `marker.line.color` and if set, `marker.line.cmax` must be set as well.

      • color
        Code: fig.update_traces(marker_line_color=<VALUE>, selector=dict(type='scatter'))
        Type: color or array of colors

        Sets the marker.line color. It accepts either a specific color or an array of numbers that are mapped to the colorscale relative to the max and min values of the array or relative to `marker.line.cmin` and `marker.line.cmax` if set.

      • coloraxis
        Code: fig.update_traces(marker_line_coloraxis=<VALUE>, selector=dict(type='scatter'))
        Type: subplotid

        Sets a reference to a shared color axis. References to these shared color axes are "coloraxis", "coloraxis2", "coloraxis3", etc. Settings for these shared color axes are set in the layout, under `layout.coloraxis`, `layout.coloraxis2`, etc. Note that multiple color scales can be linked to the same color axis.

      • colorscale
        Code: fig.update_traces(marker_line_colorscale=<VALUE>, selector=dict(type='scatter'))
        Type: colorscale

        Sets the colorscale. Has an effect only if in `marker.line.color` is set to a numerical array. The colorscale must be an array containing arrays mapping a normalized value to an rgb, rgba, hex, hsl, hsv, or named color string. At minimum, a mapping for the lowest (0) and highest (1) values are required. For example, `[[0, 'rgb(0,0,255)'], [1, 'rgb(255,0,0)']]`. To control the bounds of the colorscale in color space, use `marker.line.cmin` and `marker.line.cmax`. Alternatively, `colorscale` may be a palette name string of the following list: Blackbody,Bluered,Blues,Cividis,Earth,Electric,Greens,Greys,Hot,Jet,Picnic,Portland,Rainbow,RdBu,Reds,Viridis,YlGnBu,YlOrRd.

      • reversescale
        Code: fig.update_traces(marker_line_reversescale=<VALUE>, selector=dict(type='scatter'))
        Type: boolean

        Reverses the color mapping if True. Has an effect only if in `marker.line.color` is set to a numerical array. If True, `marker.line.cmin` will correspond to the last color in the array and `marker.line.cmax` will correspond to the first color.

      • width
        Code: fig.update_traces(marker_line_width=<VALUE>, selector=dict(type='scatter'))
        Type: number or array of numbers greater than or equal to 0

        Sets the width (in px) of the lines bounding the marker points.

    • maxdisplayed
      Code: fig.update_traces(marker_maxdisplayed=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0
      Default: 0

      Sets a maximum number of points to be drawn on the graph. "0" corresponds to no limit.

    • opacity
      Code: fig.update_traces(marker_opacity=<VALUE>, selector=dict(type='scatter'))
      Type: number or array of numbers between or equal to 0 and 1

      Sets the marker opacity.

    • reversescale
      Code: fig.update_traces(marker_reversescale=<VALUE>, selector=dict(type='scatter'))
      Type: boolean

      Reverses the color mapping if True. Has an effect only if in `marker.color` is set to a numerical array. If True, `marker.cmin` will correspond to the last color in the array and `marker.cmax` will correspond to the first color.

    • showscale
      Code: fig.update_traces(marker_showscale=<VALUE>, selector=dict(type='scatter'))
      Type: boolean

      Determines whether or not a colorbar is displayed for this trace. Has an effect only if in `marker.color` is set to a numerical array.

    • size
      Code: fig.update_traces(marker_size=<VALUE>, selector=dict(type='scatter'))
      Type: number or array of numbers greater than or equal to 0
      Default: 6

      Sets the marker size (in px).

    • sizemin
      Code: fig.update_traces(marker_sizemin=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0
      Default: 0

      Has an effect only if `marker.size` is set to a numerical array. Sets the minimum size (in px) of the rendered marker points.

    • sizemode
      Code: fig.update_traces(marker_sizemode=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated , one of ( "diameter" | "area" )
      Default: "diameter"

      Has an effect only if `marker.size` is set to a numerical array. Sets the rule for which the data in `size` is converted to pixels.

    • sizeref
      Code: fig.update_traces(marker_sizeref=<VALUE>, selector=dict(type='scatter'))
      Type: number
      Default: 1

      Has an effect only if `marker.size` is set to a numerical array. Sets the scale factor used to determine the rendered size of marker points. Use with `sizemin` and `sizemode`.

    • standoff
      Code: fig.update_traces(marker_standoff=<VALUE>, selector=dict(type='scatter'))
      Type: number or array of numbers greater than or equal to 0
      Default: 0

      Moves the marker away from the data point in the direction of `angle` (in px). This can be useful for example if you have another marker at this location and you want to point an arrowhead marker at it.

    • symbol
      Code: fig.update_traces(marker_symbol=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated or array of enumerateds , one of ( "0" | "0" | "circle" | "100" | "100" | "circle-open" | "200" | "200" | "circle-dot" | "300" | "300" | "circle-open-dot" | "1" | "1" | "square" | "101" | "101" | "square-open" | "201" | "201" | "square-dot" | "301" | "301" | "square-open-dot" | "2" | "2" | "diamond" | "102" | "102" | "diamond-open" | "202" | "202" | "diamond-dot" | "302" | "302" | "diamond-open-dot" | "3" | "3" | "cross" | "103" | "103" | "cross-open" | "203" | "203" | "cross-dot" | "303" | "303" | "cross-open-dot" | "4" | "4" | "x" | "104" | "104" | "x-open" | "204" | "204" | "x-dot" | "304" | "304" | "x-open-dot" | "5" | "5" | "triangle-up" | "105" | "105" | "triangle-up-open" | "205" | "205" | "triangle-up-dot" | "305" | "305" | "triangle-up-open-dot" | "6" | "6" | "triangle-down" | "106" | "106" | "triangle-down-open" | "206" | "206" | "triangle-down-dot" | "306" | "306" | "triangle-down-open-dot" | "7" | "7" | "triangle-left" | "107" | "107" | "triangle-left-open" | "207" | "207" | "triangle-left-dot" | "307" | "307" | "triangle-left-open-dot" | "8" | "8" | "triangle-right" | "108" | "108" | "triangle-right-open" | "208" | "208" | "triangle-right-dot" | "308" | "308" | "triangle-right-open-dot" | "9" | "9" | "triangle-ne" | "109" | "109" | "triangle-ne-open" | "209" | "209" | "triangle-ne-dot" | "309" | "309" | "triangle-ne-open-dot" | "10" | "10" | "triangle-se" | "110" | "110" | "triangle-se-open" | "210" | "210" | "triangle-se-dot" | "310" | "310" | "triangle-se-open-dot" | "11" | "11" | "triangle-sw" | "111" | "111" | "triangle-sw-open" | "211" | "211" | "triangle-sw-dot" | "311" | "311" | "triangle-sw-open-dot" | "12" | "12" | "triangle-nw" | "112" | "112" | "triangle-nw-open" | "212" | "212" | "triangle-nw-dot" | "312" | "312" | "triangle-nw-open-dot" | "13" | "13" | "pentagon" | "113" | "113" | "pentagon-open" | "213" | "213" | "pentagon-dot" | "313" | "313" | "pentagon-open-dot" | "14" | "14" | "hexagon" | "114" | "114" | "hexagon-open" | "214" | "214" | "hexagon-dot" | "314" | "314" | "hexagon-open-dot" | "15" | "15" | "hexagon2" | "115" | "115" | "hexagon2-open" | "215" | "215" | "hexagon2-dot" | "315" | "315" | "hexagon2-open-dot" | "16" | "16" | "octagon" | "116" | "116" | "octagon-open" | "216" | "216" | "octagon-dot" | "316" | "316" | "octagon-open-dot" | "17" | "17" | "star" | "117" | "117" | "star-open" | "217" | "217" | "star-dot" | "317" | "317" | "star-open-dot" | "18" | "18" | "hexagram" | "118" | "118" | "hexagram-open" | "218" | "218" | "hexagram-dot" | "318" | "318" | "hexagram-open-dot" | "19" | "19" | "star-triangle-up" | "119" | "119" | "star-triangle-up-open" | "219" | "219" | "star-triangle-up-dot" | "319" | "319" | "star-triangle-up-open-dot" | "20" | "20" | "star-triangle-down" | "120" | "120" | "star-triangle-down-open" | "220" | "220" | "star-triangle-down-dot" | "320" | "320" | "star-triangle-down-open-dot" | "21" | "21" | "star-square" | "121" | "121" | "star-square-open" | "221" | "221" | "star-square-dot" | "321" | "321" | "star-square-open-dot" | "22" | "22" | "star-diamond" | "122" | "122" | "star-diamond-open" | "222" | "222" | "star-diamond-dot" | "322" | "322" | "star-diamond-open-dot" | "23" | "23" | "diamond-tall" | "123" | "123" | "diamond-tall-open" | "223" | "223" | "diamond-tall-dot" | "323" | "323" | "diamond-tall-open-dot" | "24" | "24" | "diamond-wide" | "124" | "124" | "diamond-wide-open" | "224" | "224" | "diamond-wide-dot" | "324" | "324" | "diamond-wide-open-dot" | "25" | "25" | "hourglass" | "125" | "125" | "hourglass-open" | "26" | "26" | "bowtie" | "126" | "126" | "bowtie-open" | "27" | "27" | "circle-cross" | "127" | "127" | "circle-cross-open" | "28" | "28" | "circle-x" | "128" | "128" | "circle-x-open" | "29" | "29" | "square-cross" | "129" | "129" | "square-cross-open" | "30" | "30" | "square-x" | "130" | "130" | "square-x-open" | "31" | "31" | "diamond-cross" | "131" | "131" | "diamond-cross-open" | "32" | "32" | "diamond-x" | "132" | "132" | "diamond-x-open" | "33" | "33" | "cross-thin" | "133" | "133" | "cross-thin-open" | "34" | "34" | "x-thin" | "134" | "134" | "x-thin-open" | "35" | "35" | "asterisk" | "135" | "135" | "asterisk-open" | "36" | "36" | "hash" | "136" | "136" | "hash-open" | "236" | "236" | "hash-dot" | "336" | "336" | "hash-open-dot" | "37" | "37" | "y-up" | "137" | "137" | "y-up-open" | "38" | "38" | "y-down" | "138" | "138" | "y-down-open" | "39" | "39" | "y-left" | "139" | "139" | "y-left-open" | "40" | "40" | "y-right" | "140" | "140" | "y-right-open" | "41" | "41" | "line-ew" | "141" | "141" | "line-ew-open" | "42" | "42" | "line-ns" | "142" | "142" | "line-ns-open" | "43" | "43" | "line-ne" | "143" | "143" | "line-ne-open" | "44" | "44" | "line-nw" | "144" | "144" | "line-nw-open" | "45" | "45" | "arrow-up" | "145" | "145" | "arrow-up-open" | "46" | "46" | "arrow-down" | "146" | "146" | "arrow-down-open" | "47" | "47" | "arrow-left" | "147" | "147" | "arrow-left-open" | "48" | "48" | "arrow-right" | "148" | "148" | "arrow-right-open" | "49" | "49" | "arrow-bar-up" | "149" | "149" | "arrow-bar-up-open" | "50" | "50" | "arrow-bar-down" | "150" | "150" | "arrow-bar-down-open" | "51" | "51" | "arrow-bar-left" | "151" | "151" | "arrow-bar-left-open" | "52" | "52" | "arrow-bar-right" | "152" | "152" | "arrow-bar-right-open" | "53" | "53" | "arrow" | "153" | "153" | "arrow-open" | "54" | "54" | "arrow-wide" | "154" | "154" | "arrow-wide-open" )
      Default: "circle"

      Sets the marker symbol type. Adding 100 is equivalent to appending "-open" to a symbol name. Adding 200 is equivalent to appending "-dot" to a symbol name. Adding 300 is equivalent to appending "-open-dot" or "dot-open" to a symbol name.

  • line
    Code: fig.update_traces(line=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.
    • backoff
      Code: fig.update_traces(line_backoff=<VALUE>, selector=dict(type='scatter'))
      Type: number or array of numbers greater than or equal to 0
      Default: "auto"

      Sets the line back off from the end point of the nth line segment (in px). This option is useful e.g. to avoid overlap with arrowhead markers. With "auto" the lines would trim before markers if `marker.angleref` is set to "previous".

    • color
      Code: fig.update_traces(line_color=<VALUE>, selector=dict(type='scatter'))
      Type: color

      Sets the line color.

    • dash
      Code: fig.update_traces(line_dash=<VALUE>, selector=dict(type='scatter'))
      Type: string
      Default: "solid"

      Sets the dash style of lines. Set to a dash type string ("solid", "dot", "dash", "longdash", "dashdot", or "longdashdot") or a dash length list in px (eg "5px,10px,2px,2px").

    • shape
      Code: fig.update_traces(line_shape=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated , one of ( "linear" | "spline" | "hv" | "vh" | "hvh" | "vhv" )
      Default: "linear"

      Determines the line shape. With "spline" the lines are drawn using spline interpolation. The other available values correspond to step-wise line shapes.

    • simplify
      Code: fig.update_traces(line_simplify=<VALUE>, selector=dict(type='scatter'))
      Type: boolean
      Default: True

      Simplifies lines by removing nearly-collinear points. When transitioning lines, it may be desirable to disable this so that the number of points along the resulting SVG path is unaffected.

    • smoothing
      Code: fig.update_traces(line_smoothing=<VALUE>, selector=dict(type='scatter'))
      Type: number between or equal to 0 and 1.3
      Default: 1

      Has an effect only if `shape` is set to "spline" Sets the amount of smoothing. "0" corresponds to no smoothing (equivalent to a "linear" shape).

    • width
      Code: fig.update_traces(line_width=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0
      Default: 2

      Sets the line width (in px).

  • textfont
    Code: fig.update_traces(textfont=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.

    Sets the text font.

    • color
      Code: fig.update_traces(textfont_color=<VALUE>, selector=dict(type='scatter'))
      Type: color or array of colors
    • family
      Code: fig.update_traces(textfont_family=<VALUE>, selector=dict(type='scatter'))
      Type: string or array of strings

      HTML font family - the typeface that will be applied by the web browser. The web browser will only be able to apply a font if it is available on the system which it operates. Provide multiple font families, separated by commas, to indicate the preference in which to apply fonts if they aren't available on the system. The Chart Studio Cloud (at https://chart-studio.plotly.com or on-premise) generates images on a server, where only a select number of fonts are installed and supported. These include "Arial", "Balto", "Courier New", "Droid Sans", "Droid Serif", "Droid Sans Mono", "Gravitas One", "Old Standard TT", "Open Sans", "Overpass", "PT Sans Narrow", "Raleway", "Times New Roman".

    • lineposition
      Code: fig.update_traces(textfont_lineposition=<VALUE>, selector=dict(type='scatter'))
      Type: flaglist string. Any combination of "under", "over", "through" joined with a "+" OR "none".
      Examples: "under", "over", "under+over", "under+over+through", "none"
      Default: "none"

      Sets the kind of decoration line(s) with text, such as an "under", "over" or "through" as well as combinations e.g. "under+over", etc.

    • shadow
      Code: fig.update_traces(textfont_shadow=<VALUE>, selector=dict(type='scatter'))
      Type: string or array of strings
      Default: "none"

      Sets the shape and color of the shadow behind text. "auto" places minimal shadow and applies contrast text font color. See https://developer.mozilla.org/en-US/docs/Web/CSS/text-shadow for additional options.

    • size
      Code: fig.update_traces(textfont_size=<VALUE>, selector=dict(type='scatter'))
      Type: number or array of numbers greater than or equal to 1
    • style
      Code: fig.update_traces(textfont_style=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated or array of enumerateds , one of ( "normal" | "italic" )
      Default: "normal"

      Sets whether a font should be styled with a normal or italic face from its family.

    • textcase
      Code: fig.update_traces(textfont_textcase=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated or array of enumerateds , one of ( "normal" | "word caps" | "upper" | "lower" )
      Default: "normal"

      Sets capitalization of text. It can be used to make text appear in all-uppercase or all-lowercase, or with each word capitalized.

    • variant
      Code: fig.update_traces(textfont_variant=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated or array of enumerateds , one of ( "normal" | "small-caps" | "all-small-caps" | "all-petite-caps" | "petite-caps" | "unicase" )
      Default: "normal"

      Sets the variant of the font.

    • weight
      Code: fig.update_traces(textfont_weight=<VALUE>, selector=dict(type='scatter'))
      Type: integer or array of integers between or equal to 1 and 1000
      Default: normal

      Sets the weight (or boldness) of the font.

  • error_x
    Code: fig.update_traces(error_x=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.
    • array
      Code: fig.update_traces(error_x_array=<VALUE>, selector=dict(type='scatter'))
      Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

      Sets the data corresponding the length of each error bar. Values are plotted relative to the underlying data.

    • arrayminus
      Code: fig.update_traces(error_x_arrayminus=<VALUE>, selector=dict(type='scatter'))
      Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

      Sets the data corresponding the length of each error bar in the bottom (left) direction for vertical (horizontal) bars Values are plotted relative to the underlying data.

    • color
      Code: fig.update_traces(error_x_color=<VALUE>, selector=dict(type='scatter'))
      Type: color

      Sets the stoke color of the error bars.

    • copy_ystyle
      Code: fig.update_traces(error_x_copy_ystyle=<VALUE>, selector=dict(type='scatter'))
      Type: boolean
    • symmetric
      Code: fig.update_traces(error_x_symmetric=<VALUE>, selector=dict(type='scatter'))
      Type: boolean

      Determines whether or not the error bars have the same length in both direction (top/bottom for vertical bars, left/right for horizontal bars.

    • thickness
      Code: fig.update_traces(error_x_thickness=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0
      Default: 2

      Sets the thickness (in px) of the error bars.

    • traceref
      Code: fig.update_traces(error_x_traceref=<VALUE>, selector=dict(type='scatter'))
      Type: integer greater than or equal to 0
      Default: 0
    • tracerefminus
      Code: fig.update_traces(error_x_tracerefminus=<VALUE>, selector=dict(type='scatter'))
      Type: integer greater than or equal to 0
      Default: 0
    • type
      Code: fig.update_traces(error_x_type=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated , one of ( "percent" | "constant" | "sqrt" | "data" )

      Determines the rule used to generate the error bars. If "constant`, the bar lengths are of a constant value. Set this constant in `value`. If "percent", the bar lengths correspond to a percentage of underlying data. Set this percentage in `value`. If "sqrt", the bar lengths correspond to the square of the underlying data. If "data", the bar lengths are set with data set `array`.

    • value
      Code: fig.update_traces(error_x_value=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0
      Default: 10

      Sets the value of either the percentage (if `type` is set to "percent") or the constant (if `type` is set to "constant") corresponding to the lengths of the error bars.

    • valueminus
      Code: fig.update_traces(error_x_valueminus=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0
      Default: 10

      Sets the value of either the percentage (if `type` is set to "percent") or the constant (if `type` is set to "constant") corresponding to the lengths of the error bars in the bottom (left) direction for vertical (horizontal) bars

    • visible
      Code: fig.update_traces(error_x_visible=<VALUE>, selector=dict(type='scatter'))
      Type: boolean

      Determines whether or not this set of error bars is visible.

    • width
      Code: fig.update_traces(error_x_width=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0

      Sets the width (in px) of the cross-bar at both ends of the error bars.

  • error_y
    Code: fig.update_traces(error_y=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.
    • array
      Code: fig.update_traces(error_y_array=<VALUE>, selector=dict(type='scatter'))
      Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

      Sets the data corresponding the length of each error bar. Values are plotted relative to the underlying data.

    • arrayminus
      Code: fig.update_traces(error_y_arrayminus=<VALUE>, selector=dict(type='scatter'))
      Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

      Sets the data corresponding the length of each error bar in the bottom (left) direction for vertical (horizontal) bars Values are plotted relative to the underlying data.

    • color
      Code: fig.update_traces(error_y_color=<VALUE>, selector=dict(type='scatter'))
      Type: color

      Sets the stoke color of the error bars.

    • symmetric
      Code: fig.update_traces(error_y_symmetric=<VALUE>, selector=dict(type='scatter'))
      Type: boolean

      Determines whether or not the error bars have the same length in both direction (top/bottom for vertical bars, left/right for horizontal bars.

    • thickness
      Code: fig.update_traces(error_y_thickness=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0
      Default: 2

      Sets the thickness (in px) of the error bars.

    • traceref
      Code: fig.update_traces(error_y_traceref=<VALUE>, selector=dict(type='scatter'))
      Type: integer greater than or equal to 0
      Default: 0
    • tracerefminus
      Code: fig.update_traces(error_y_tracerefminus=<VALUE>, selector=dict(type='scatter'))
      Type: integer greater than or equal to 0
      Default: 0
    • type
      Code: fig.update_traces(error_y_type=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated , one of ( "percent" | "constant" | "sqrt" | "data" )

      Determines the rule used to generate the error bars. If "constant`, the bar lengths are of a constant value. Set this constant in `value`. If "percent", the bar lengths correspond to a percentage of underlying data. Set this percentage in `value`. If "sqrt", the bar lengths correspond to the square of the underlying data. If "data", the bar lengths are set with data set `array`.

    • value
      Code: fig.update_traces(error_y_value=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0
      Default: 10

      Sets the value of either the percentage (if `type` is set to "percent") or the constant (if `type` is set to "constant") corresponding to the lengths of the error bars.

    • valueminus
      Code: fig.update_traces(error_y_valueminus=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0
      Default: 10

      Sets the value of either the percentage (if `type` is set to "percent") or the constant (if `type` is set to "constant") corresponding to the lengths of the error bars in the bottom (left) direction for vertical (horizontal) bars

    • visible
      Code: fig.update_traces(error_y_visible=<VALUE>, selector=dict(type='scatter'))
      Type: boolean

      Determines whether or not this set of error bars is visible.

    • width
      Code: fig.update_traces(error_y_width=<VALUE>, selector=dict(type='scatter'))
      Type: number greater than or equal to 0

      Sets the width (in px) of the cross-bar at both ends of the error bars.

  • selectedpoints
    Code: fig.update_traces(selectedpoints=<VALUE>, selector=dict(type='scatter'))
    Type: number or categorical coordinate string

    Array containing integer indices of selected points. Has an effect only for traces that support selections. Note that an empty array means an empty selection where the `unselected` are turned on for all points, whereas, any other non-array values means no selection all where the `selected` and `unselected` styles have no effect.

  • selected
    Code: fig.update_traces(selected=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.
    • marker
      Code: fig.update_traces(selected_marker=dict(...), selector=dict(type='scatter'))
      Type: dict containing one or more of the keys listed below.
      • color
        Code: fig.update_traces(selected_marker_color=<VALUE>, selector=dict(type='scatter'))
        Type: color

        Sets the marker color of selected points.

      • opacity
        Code: fig.update_traces(selected_marker_opacity=<VALUE>, selector=dict(type='scatter'))
        Type: number between or equal to 0 and 1

        Sets the marker opacity of selected points.

      • size
        Code: fig.update_traces(selected_marker_size=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0

        Sets the marker size of selected points.

    • textfont
      Code: fig.update_traces(selected_textfont=dict(...), selector=dict(type='scatter'))
      Type: dict containing one or more of the keys listed below.
      • color
        Code: fig.update_traces(selected_textfont_color=<VALUE>, selector=dict(type='scatter'))
        Type: color

        Sets the text font color of selected points.

  • unselected
    Code: fig.update_traces(unselected=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.
    • marker
      Code: fig.update_traces(unselected_marker=dict(...), selector=dict(type='scatter'))
      Type: dict containing one or more of the keys listed below.
      • color
        Code: fig.update_traces(unselected_marker_color=<VALUE>, selector=dict(type='scatter'))
        Type: color

        Sets the marker color of unselected points, applied only when a selection exists.

      • opacity
        Code: fig.update_traces(unselected_marker_opacity=<VALUE>, selector=dict(type='scatter'))
        Type: number between or equal to 0 and 1

        Sets the marker opacity of unselected points, applied only when a selection exists.

      • size
        Code: fig.update_traces(unselected_marker_size=<VALUE>, selector=dict(type='scatter'))
        Type: number greater than or equal to 0

        Sets the marker size of unselected points, applied only when a selection exists.

    • textfont
      Code: fig.update_traces(unselected_textfont=dict(...), selector=dict(type='scatter'))
      Type: dict containing one or more of the keys listed below.
      • color
        Code: fig.update_traces(unselected_textfont_color=<VALUE>, selector=dict(type='scatter'))
        Type: color

        Sets the text font color of unselected points, applied only when a selection exists.

  • cliponaxis
    Code: fig.update_traces(cliponaxis=<VALUE>, selector=dict(type='scatter'))
    Type: boolean
    Default: True

    Determines whether or not markers and text nodes are clipped about the subplot axes. To show markers and text nodes above axis lines and tick labels, make sure to set `xaxis.layer` and `yaxis.layer` to "below traces".

  • connectgaps
    Code: fig.update_traces(connectgaps=<VALUE>, selector=dict(type='scatter'))
    Type: boolean

    Determines whether or not gaps (i.e. {nan} or missing values) in the provided data arrays are connected.

  • fill
    Code: fig.update_traces(fill=<VALUE>, selector=dict(type='scatter'))
    Type: enumerated , one of ( "none" | "tozeroy" | "tozerox" | "tonexty" | "tonextx" | "toself" | "tonext" )

    Sets the area to fill with a solid color. Defaults to "none" unless this trace is stacked, then it gets "tonexty" ("tonextx") if `orientation` is "v" ("h") Use with `fillcolor` if not "none". "tozerox" and "tozeroy" fill to x=0 and y=0 respectively. "tonextx" and "tonexty" fill between the endpoints of this trace and the endpoints of the trace before it, connecting those endpoints with straight lines (to make a stacked area graph); if there is no trace before it, they behave like "tozerox" and "tozeroy". "toself" connects the endpoints of the trace (or each segment of the trace if it has gaps) into a closed shape. "tonext" fills the space between two traces if one completely encloses the other (eg consecutive contour lines), and behaves like "toself" if there is no trace before it. "tonext" should not be used if one trace does not enclose the other. Traces in a `stackgroup` will only fill to (or be filled to) other traces in the same group. With multiple `stackgroup`s or some traces stacked and some not, if fill-linked traces are not already consecutive, the later ones will be pushed down in the drawing order.

  • fillcolor
    Code: fig.update_traces(fillcolor=<VALUE>, selector=dict(type='scatter'))
    Type: color

    Sets the fill color. Defaults to a half-transparent variant of the line color, marker color, or marker line color, whichever is available. If fillgradient is specified, fillcolor is ignored except for setting the background color of the hover label, if any.

  • fillgradient
    Code: fig.update_traces(fillgradient=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.

    Sets a fill gradient. If not specified, the fillcolor is used instead.

    • colorscale
      Code: fig.update_traces(fillgradient_colorscale=<VALUE>, selector=dict(type='scatter'))
      Type: colorscale

      Sets the fill gradient colors as a color scale. The color scale is interpreted as a gradient applied in the direction specified by "orientation", from the lowest to the highest value of the scatter plot along that axis, or from the center to the most distant point from it, if orientation is "radial".

    • start
      Code: fig.update_traces(fillgradient_start=<VALUE>, selector=dict(type='scatter'))
      Type: number

      Sets the gradient start value. It is given as the absolute position on the axis determined by the orientiation. E.g., if orientation is "horizontal", the gradient will be horizontal and start from the x-position given by start. If omitted, the gradient starts at the lowest value of the trace along the respective axis. Ignored if orientation is "radial".

    • stop
      Code: fig.update_traces(fillgradient_stop=<VALUE>, selector=dict(type='scatter'))
      Type: number

      Sets the gradient end value. It is given as the absolute position on the axis determined by the orientiation. E.g., if orientation is "horizontal", the gradient will be horizontal and end at the x-position given by end. If omitted, the gradient ends at the highest value of the trace along the respective axis. Ignored if orientation is "radial".

    • type
      Code: fig.update_traces(fillgradient_type=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated , one of ( "radial" | "horizontal" | "vertical" | "none" )
      Default: "none"

      Sets the type/orientation of the color gradient for the fill. Defaults to "none".

  • fillpattern
    Code: fig.update_traces(fillpattern=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.

    Sets the pattern within the marker.

    • bgcolor
      Code: fig.update_traces(fillpattern_bgcolor=<VALUE>, selector=dict(type='scatter'))
      Type: color or array of colors

      When there is no colorscale sets the color of background pattern fill. Defaults to a `marker.color` background when `fillmode` is "overlay". Otherwise, defaults to a transparent background.

    • fgcolor
      Code: fig.update_traces(fillpattern_fgcolor=<VALUE>, selector=dict(type='scatter'))
      Type: color or array of colors

      When there is no colorscale sets the color of foreground pattern fill. Defaults to a `marker.color` background when `fillmode` is "replace". Otherwise, defaults to dark grey or white to increase contrast with the `bgcolor`.

    • fgopacity
      Code: fig.update_traces(fillpattern_fgopacity=<VALUE>, selector=dict(type='scatter'))
      Type: number between or equal to 0 and 1

      Sets the opacity of the foreground pattern fill. Defaults to a 0.5 when `fillmode` is "overlay". Otherwise, defaults to 1.

    • fillmode
      Code: fig.update_traces(fillpattern_fillmode=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated , one of ( "replace" | "overlay" )
      Default: "replace"

      Determines whether `marker.color` should be used as a default to `bgcolor` or a `fgcolor`.

    • shape
      Code: fig.update_traces(fillpattern_shape=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated or array of enumerateds , one of ( "" | "/" | "\" | "x" | "-" | "|" | "+" | "." )
      Default: ""

      Sets the shape of the pattern fill. By default, no pattern is used for filling the area.

    • size
      Code: fig.update_traces(fillpattern_size=<VALUE>, selector=dict(type='scatter'))
      Type: number or array of numbers greater than or equal to 0
      Default: 8

      Sets the size of unit squares of the pattern fill in pixels, which corresponds to the interval of repetition of the pattern.

    • solidity
      Code: fig.update_traces(fillpattern_solidity=<VALUE>, selector=dict(type='scatter'))
      Type: number or array of numbers between or equal to 0 and 1
      Default: 0.3

      Sets the solidity of the pattern fill. Solidity is roughly the fraction of the area filled by the pattern. Solidity of 0 shows only the background color without pattern and solidty of 1 shows only the foreground color without pattern.

  • hoverlabel
    Code: fig.update_traces(hoverlabel=dict(...), selector=dict(type='scatter'))
    Type: dict containing one or more of the keys listed below.
    • align
      Code: fig.update_traces(hoverlabel_align=<VALUE>, selector=dict(type='scatter'))
      Type: enumerated or array of enumerateds , one of ( "left" | "right" | "auto" )
      Default: "auto"

      Sets the horizontal alignment of the text content within hover label box. Has an effect only if the hover label text spans more two or more lines

    • bgcolor
      Code: fig.update_traces(hoverlabel_bgcolor=<VALUE>, selector=dict(type='scatter'))
      Type: color or array of colors

      Sets the background color of the hover labels for this trace

    • bordercolor
      Code: fig.update_traces(hoverlabel_bordercolor=<VALUE>, selector=dict(type='scatter'))
      Type: color or array of colors

      Sets the border color of the hover labels for this trace.

    • font
      Code: fig.update_traces(hoverlabel_font=dict(...), selector=dict(type='scatter'))
      Type: dict containing one or more of the keys listed below.

      Sets the font used in hover labels.

      • color
        Code: fig.update_traces(hoverlabel_font_color=<VALUE>, selector=dict(type='scatter'))
        Type: color or array of colors
      • family
        Code: fig.update_traces(hoverlabel_font_family=<VALUE>, selector=dict(type='scatter'))
        Type: string or array of strings

        HTML font family - the typeface that will be applied by the web browser. The web browser will only be able to apply a font if it is available on the system which it operates. Provide multiple font families, separated by commas, to indicate the preference in which to apply fonts if they aren't available on the system. The Chart Studio Cloud (at https://chart-studio.plotly.com or on-premise) generates images on a server, where only a select number of fonts are installed and supported. These include "Arial", "Balto", "Courier New", "Droid Sans", "Droid Serif", "Droid Sans Mono", "Gravitas One", "Old Standard TT", "Open Sans", "Overpass", "PT Sans Narrow", "Raleway", "Times New Roman".

      • lineposition
        Code: fig.update_traces(hoverlabel_font_lineposition=<VALUE>, selector=dict(type='scatter'))
        Type: flaglist string. Any combination of "under", "over", "through" joined with a "+" OR "none".
        Examples: "under", "over", "under+over", "under+over+through", "none"
        Default: "none"

        Sets the kind of decoration line(s) with text, such as an "under", "over" or "through" as well as combinations e.g. "under+over", etc.

      • shadow
        Code: fig.update_traces(hoverlabel_font_shadow=<VALUE>, selector=dict(type='scatter'))
        Type: string or array of strings
        Default: "none"

        Sets the shape and color of the shadow behind text. "auto" places minimal shadow and applies contrast text font color. See https://developer.mozilla.org/en-US/docs/Web/CSS/text-shadow for additional options.

      • size
        Code: fig.update_traces(hoverlabel_font_size=<VALUE>, selector=dict(type='scatter'))
        Type: number or array of numbers greater than or equal to 1
      • style
        Code: fig.update_traces(hoverlabel_font_style=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated or array of enumerateds , one of ( "normal" | "italic" )
        Default: "normal"

        Sets whether a font should be styled with a normal or italic face from its family.

      • textcase
        Code: fig.update_traces(hoverlabel_font_textcase=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated or array of enumerateds , one of ( "normal" | "word caps" | "upper" | "lower" )
        Default: "normal"

        Sets capitalization of text. It can be used to make text appear in all-uppercase or all-lowercase, or with each word capitalized.

      • variant
        Code: fig.update_traces(hoverlabel_font_variant=<VALUE>, selector=dict(type='scatter'))
        Type: enumerated or array of enumerateds , one of ( "normal" | "small-caps" | "all-small-caps" | "all-petite-caps" | "petite-caps" | "unicase" )
        Default: "normal"

        Sets the variant of the font.

      • weight
        Code: fig.update_traces(hoverlabel_font_weight=<VALUE>, selector=dict(type='scatter'))
        Type: integer or array of integers between or equal to 1 and 1000
        Default: normal

        Sets the weight (or boldness) of the font.

    • namelength
      Code: fig.update_traces(hoverlabel_namelength=<VALUE>, selector=dict(type='scatter'))
      Type: integer or array of integers greater than or equal to -1
      Default: 15

      Sets the default length (in number of characters) of the trace name in the hover labels for all traces. -1 shows the whole name regardless of length. 0-3 shows the first 0-3 characters, and an integer >3 will show the whole name if it is less than that many characters, but if it is longer, will truncate to `namelength - 3` characters and add an ellipsis.

  • hoveron
    Code: fig.update_traces(hoveron=<VALUE>, selector=dict(type='scatter'))
    Type: flaglist string. Any combination of "points", "fills" joined with a "+"
    Examples: "points", "fills", "points+fills"

    Do the hover effects highlight individual points (markers or line points) or do they highlight filled regions? If the fill is "toself" or "tonext" and there are no markers or text, then the default is "fills", otherwise it is "points".

  • stackgaps
    Code: fig.update_traces(stackgaps=<VALUE>, selector=dict(type='scatter'))
    Type: enumerated , one of ( "infer zero" | "interpolate" )
    Default: "infer zero"

    Only relevant when `stackgroup` is used, and only the first `stackgaps` found in the `stackgroup` will be used - including if `visible` is "legendonly" but not if it is `False`. Determines how we handle locations at which other traces in this group have data but this one does not. With "infer zero" we insert a zero at these locations. With "interpolate" we linearly interpolate between existing values, and extrapolate a constant beyond the existing values.

  • xcalendar
    Code: fig.update_traces(xcalendar=<VALUE>, selector=dict(type='scatter'))
    Type: enumerated , one of ( "chinese" | "coptic" | "discworld" | "ethiopian" | "gregorian" | "hebrew" | "islamic" | "jalali" | "julian" | "mayan" | "nanakshahi" | "nepali" | "persian" | "taiwan" | "thai" | "ummalqura" )
    Default: "gregorian"

    Sets the calendar system to use with `x` date data.

  • ycalendar
    Code: fig.update_traces(ycalendar=<VALUE>, selector=dict(type='scatter'))
    Type: enumerated , one of ( "chinese" | "coptic" | "discworld" | "ethiopian" | "gregorian" | "hebrew" | "islamic" | "jalali" | "julian" | "mayan" | "nanakshahi" | "nepali" | "persian" | "taiwan" | "thai" | "ummalqura" )
    Default: "gregorian"

    Sets the calendar system to use with `y` date data.

  • uirevision
    Code: fig.update_traces(uirevision=<VALUE>, selector=dict(type='scatter'))
    Type: number or categorical coordinate string

    Controls persistence of some user-driven changes to the trace: `constraintrange` in `parcoords` traces, as well as some `editable: True` modifications such as `name` and `colorbar.title`. Defaults to `layout.uirevision`. Note that other user-driven trace attribute changes are controlled by `layout` attributes: `trace.visible` is controlled by `layout.legend.uirevision`, `selectedpoints` is controlled by `layout.selectionrevision`, and `colorbar.(x|y)` (accessible with `config: {editable: True}`) is controlled by `layout.editrevision`. Trace changes are tracked by `uid`, which only falls back on trace index if no `uid` is provided. So if your app can add/remove traces before the end of the `data` array, such that the same trace has a different index, you can still preserve user-driven changes if you give each trace a `uid` that stays with it as it moves.
