Graphing Multiple Chart Types in R

How to design figures with multiple chart types in R. An example of a line chart with a line of best fit and an uncertainty band.


New to Plotly?

Plotly is a free and open-source graphing library for R. We recommend you read our Getting Started guide for the latest installation or upgrade instructions, then move on to our Plotly Fundamentals tutorials or dive straight in to some Basic Charts tutorials.

Bar and Line Chart

library(plotly)

airquality_sept <- airquality[which(airquality$Month == 9),]
airquality_sept$Date <- as.Date(paste(airquality_sept$Month, airquality_sept$Day, 1973, sep = "."), format = "%m.%d.%Y")

fig <- plot_ly(airquality_sept)
fig <- fig %>% add_trace(x = ~Date, y = ~Wind, type = 'bar', name = 'Wind',
            marker = list(color = '#C9EFF9'),
            hoverinfo = "text",
            text = ~paste(Wind, ' mph'))
fig <- fig %>% add_trace(x = ~Date, y = ~Temp, type = 'scatter', mode = 'lines', name = 'Temperature', yaxis = 'y2',
            line = list(color = '#45171D'),
            hoverinfo = "text",
            text = ~paste(Temp, '°F'))
fig <- fig %>% layout(title = 'New York Wind and Temperature Measurements for September 1973',
         xaxis = list(title = ""),
         yaxis = list(side = 'left', title = 'Wind in mph', showgrid = FALSE, zeroline = FALSE),
         yaxis2 = list(side = 'right', overlaying = "y", title = 'Temperature in degrees F', showgrid = FALSE, zeroline = FALSE))

fig

Scatterplot with Loess Smoother

library(plotly)

fig <- plot_ly(mtcars, x = ~disp, color = I("black"))
fig <- fig %>% add_markers(y = ~mpg, text = rownames(mtcars), showlegend = FALSE)
fig <- fig %>% add_lines(y = ~fitted(loess(mpg ~ disp)),
            line = list(color = '#07A4B5'),
            name = "Loess Smoother", showlegend = TRUE)
fig <- fig %>% layout(xaxis = list(title = 'Displacement (cu.in.)'),
         yaxis = list(title = 'Miles/(US) gallon'),
         legend = list(x = 0.80, y = 0.90))

fig

Loess Smoother with Uncertainty Bounds

library(plotly)
library(broom)

m <- loess(mpg ~ disp, data = mtcars)

fig <- plot_ly(mtcars, x = ~disp, color = I("black"))
fig <- fig %>% add_markers(y = ~mpg, text = rownames(mtcars), showlegend = FALSE)
fig <- fig %>% add_lines(y = ~fitted(loess(mpg ~ disp)),
            line = list(color = 'rgba(7, 164, 181, 1)'),
            name = "Loess Smoother")
fig <- fig %>% add_ribbons(data = augment(m),
              ymin = ~.fitted - 1.96 * .se.fit,
              ymax = ~.fitted + 1.96 * .se.fit,
              line = list(color = 'rgba(7, 164, 181, 0.05)'),
              fillcolor = 'rgba(7, 164, 181, 0.2)',
              name = "Standard Error")
fig <- fig %>% layout(xaxis = list(title = 'Displacement (cu.in.)'),
         yaxis = list(title = 'Miles/(US) gallon'),
         legend = list(x = 0.80, y = 0.90))

fig

Reference

See https://plotly.com/r/reference/ for more information and chart attribute options!

What About Dash?

Dash for R is an open-source framework for building analytical applications, with no Javascript required, and it is tightly integrated with the Plotly graphing library.

Learn about how to install Dash for R at https://dashr.plot.ly/installation.

Everywhere in this page that you see fig, you can display the same figure in a Dash for R application by passing it to the figure argument of the Graph component from the built-in dashCoreComponents package like this:

library(plotly)

fig <- plot_ly()
# fig <- fig %>% add_trace( ... )
# fig <- fig %>% layout( ... )

library(dash)
library(dashCoreComponents)
library(dashHtmlComponents)

app <- Dash$new()
app$layout(
    htmlDiv(
        list(
            dccGraph(figure=fig)
        )
     )
)

app$run_server(debug=TRUE, dev_tools_hot_reload=FALSE)
