LaTeX in JavaScript

Plotly.js renders LaTeX in titles, axis labels, annotations, and legend entries when MathJax is loaded on the page. Wrap the expression in $ delimiters, as in the example below.

Plotly.js v4 supports MathJax v3 and v4, and uses the tex-svg component. Load one of the following before plotly.js:

<!-- MathJax v3 -->
<script src="https://cdn.jsdelivr.net/npm/mathjax@3.2.2/es5/tex-svg.js"></script>
<!-- or MathJax v4 -->
<script src="https://cdn.jsdelivr.net/npm/mathjax@4/tex-svg.js"></script>

MathJax v2 is no longer supported. If your page loads MathJax.js?config=TeX-MML-AM_CHTML, replace it with one of the tags above — the ?config= query string is not used from MathJax v3 onward, since the component is selected by the file you load.

// remember to load MathJax v3 or v4 (tex-svg.js) - see https://plotly.com/javascript/LaTeX/
var trace1 = {
  x: [1, 2, 3, 4],
  y: [1, 4, 9, 16],
  name: '$\\alpha_{1c} = 352 \\pm 11 \\text{ km s}^{-1}$',
  type: 'scatter'
};
var trace2 = {
  x: [1, 2, 3, 4],
  y: [0.5, 2, 4.5, 8],
  name: '$\\beta_{1c} = 25 \\pm 11 \\text{ km s}^{-1}$',
  type: 'scatter'
};
var data = [trace1, trace2];
var layout = {
  xaxis: {
    title: {
      text: '$\\sqrt{(n_\\text{c}(t|{T_\\text{early}}))}$'
    }
  },
  yaxis: {
    title: {
      text: '$d, r \\text{ (solar radius)}$'
    }
  }
};
Plotly.newPlot('myDiv', data, layout);
